ESP-IDF Workshop: Advanced

Table of Contents

Welcome to the advanced ESP-IDF workshop!

Introduction
#

In this workshop, we’ll explore some of the more advanced aspects of the ESP-IDF framework, including modular development using components, the event loop, core dumps, and security features.

Estimated time: 3 hours.

Agenda
#

The workshop is divided into four parts.

  • Part 1: Components

    • Lesson 1 – What a component is, how to create one, and how to support multiple hardware versions through BSPs and multiple configurations
    • Assignment 1.1 – Refactor the code by creating the alarm component (Guided)
    • Assignment 1.2 – Refactor the code by creating the cloud_manager component
    • Assignment 1.3 – Manage multiple configurations using sdkconfig (Guided)

  • Part 2: Event Loop

    • Lesson 2 – Basic information about event loops in ESP-IDF, using timer events, and separating responsibilities
    • Assignment 2.1 – Refactor the code to use the event loop (Guided)
    • Assignment 2.2 – Add a GPIO event to the event loop

  • Part 3: Performance and Crash Analysis

    • Lesson 3 – Size analysis and using core dumps for debugging
    • Assignment 3.1 – Analyze the application size and suggest optimizations (Guided)
    • Assignment 3.2 – Analyze a crash using core dumps (Guided)
    • Assignment 3.3 – Analyze a crash using core dumps (Optional)

  • Part 4: OTA and Security Features

    • Lesson 4 – Fundamentals of OTA, partition table configuration, secure bootloader, and flash encryption
    • Assignment 4.1 – Modify the partition table to support OTA (Guided)
    • Assignment 4.2 – Use a custom partition table (Guided)
    • Assignment 4.3 – Enable flash encryption (Guided)

Prerequisites
#

To follow this workshop, make sure you meet the prerequisites listed below.

Required Software
#

Required Hardware
#

  • ESP-C3-DevKit-RUST-1 or ESP-C3-DevKit-RUST-2 board (if the activity is in person, the board will be provided during the workshop)
    It is also possible to use an ESP32-C3-DevKit-M/C board, but you will need to adjust the GPIO configuration accordingly.
If the event is held in person, it is strongly recommended to install VS Code and the ESP-IDF plugin before the start of the workshop. If you encounter any issues, there will still be a short time during the first exercise to complete the installation.

Basic Knowledge
#

  • Good understanding of:
    • C programming and the linker
    • Callback functions and function pointers
    • MQTT protocol and its use
  • Embedded programming
    • Flashing / Programming, linking
    • Familiarity with MCU peripherals such as GPIO and I2C
    • Basic experience with ESP-IDF
  • Tool installation (VS Code + ESP-IDF extension)

Next Step
#

If you are unable to complete an exercise during the session, you can continue by downloading the appropriate solution according to the following structure:

aassssiiggnnmmeenntt__13__12__bbaasseeassignment_1_1assignmentaa_ss1ss_ii2ggnnmmeenntt__a23s__s12ignmentaa_ss1ss_ii3ggnnmmeenntt__24__21aassssiiggnnmmeenntt__34__12

Even if you successfully complete all exercises, you will still need to download at least assignment_1_1_base and assignment_3_2_base: The first assignment is based on the code in assignment_1_1_base

Your next step is Lesson 1.

Conclusion
#

Congratulations! You have reached the end of this workshop. We hope it has been a valuable experience and the start of a longer learning journey. Thank you for participating in the advanced ESP-IDF workshop.
